Variable Internal Angle CABLOMAX 130x55mm

The Cablomax 130x55 mm Adjustable Internal Angle is an accessory designed to facilitate the proper installation of electrical trunking systems, allowing for precise and safe internal turns between different planes.

This component is specifically designed for use with Cablomax 130x55 mm trunking, providing an effective solution for adapting to changes in direction in both wall and ceiling installations.

Its main advantage is its variable adjustment capability, allowing it to adapt to angles between 65º and 95º, making it a versatile element capable of solving multiple on-site situations without the need for additional parts.

Manufactured from PVC (high-quality thermoplastic) with a white finish, this accessory ensures seamless aesthetic integration with the trunking, maintaining a clean and professional appearance throughout the installation.

Main features include:

• Compatible with Cablomax 130x55 mm trunking
• Adjustable internal angle between 65º and 95º
• Made from high-resistance PVC
• White finish for aesthetic integration
• Suitable for wall and ceiling installation

Additionally, it can be combined with other system accessories and with solutions from the K45 range, expanding its application possibilities in electrical and telecommunications installations.

From a technical standpoint, this accessory offers a high level of performance and safety:

• Impact resistance rating: IK07
• Protection degree: IP4X
• Heat resistance: up to +125 ºC (according to IEC 60695-10-2)
• Maximum working temperature: 120 ºC
• Installation temperature range: from -25 to +120 ºC
• Depth: 55 mm
• Available market: CE

Thanks to these features, the adjustable internal angle ensures excellent durability and performance even under demanding conditions, maintaining the safety and integrity of the installation.

The product is designed for robust and secure installation, allowing for wall or ceiling mounting. Removal of its components and cover can only be done with tools, preventing unwanted tampering and enhancing system reliability.

For maintenance:

• Clean with a soft, dry cloth
• Do not use abrasive products
• Avoid cleaners containing chlorine

The Cablomax adjustable internal angle is an essential solution for achieving professional finishes in trunking installations, making it easy to adapt to any environment without compromising aesthetics or functionality.

A highly practical piece for construction projects that simplifies complex turns and helps achieve a clean, well-aligned, and durable result.
